Simple salts make PEDOT:PSS plastic grow conductive fibres for flexible electronics

Researchers have found that mixing straightforward salts into a soft, gel-like conducting plastic used in flexible electronics prompts it to develop dense webs of microscopic fibres that transport electricity far better than the material does in its smoother state.

That shift in structure suggests a route towards soft electronic components that can stay highly flexible while maintaining reliable conductivity-an especially important combination for implantable devices that must endure the constant motion and chemistry inside the human body.

Salt-enhanced plastic

Within the gel, long, whisker-like filaments thread through the material, creating consistent routes along which electrical charge can travel.

By probing these features, Enrique Gomez, a professor of chemical engineering at Pennsylvania State University (Penn State), tracked how small amounts of salt set off the formation of far greater numbers of these fibres.

When the researchers tried different salt blends, the plastic produced more of the filament network and allowed charge to move more freely, without turning rigid.

This connection between simple salt additives and the polymer’s concealed architecture helps clarify how the material can remain soft while still conducting electricity.

Challenges in bioelectronics

In the body, signals propagate through watery salts and charged ions, rather than through copper wiring and silicon components.

When an electrode is stiff inside an organ that moves, it can rub, warm, or scar tissue, and the recorded signal may shift over time.

For years, engineers have pursued soft conductive materials, yet many lose performance when they are stretched, when they dry out, or when they develop cracks.

Improved options must deliver current while staying as compliant as skin, cartilage, and muscle.

A conducting plastic surprise

A dark blue plastic coating already appears in many flexible sensors, typically cast from water into thin films.

Known as PEDOT:PSS, it can carry two forms of charge simultaneously: the electronic charge common in devices and the ionic charge present in biological systems.

That dual-conduction behaviour helps the film keep functioning even when exposed to sweat or other salty fluids in the body.

Until now, groups could measure strong results after adding salts, but what happened inside the material was largely hidden.

Imaging with cryo-EM

To look inside the gel, the team turned to cryo-EM, an electron microscope technique that images specimens while frozen.

Rather than passing light through optical lenses, cryo-EM sends electrons through an ultrathin film-only a small fraction of the width of a human hair.

After being rapidly plunged into liquid ethane at about −180°C (−292°F), the droplet solidified before the electron beam could damage it.

This rapid freezing held the molecules in place, allowing cryo-EM to resolve the strands that would otherwise smear under conventional room-temperature imaging.

Salts shape the network

Cryo-EM images showed that samples containing added salts had many more elongated fibres than samples prepared without those additives.

The salts altered how the polymer chains arranged themselves as the material dried, producing longer conductive routes that let electricity travel with less resistance.

In the same salt-treated samples, the researchers also observed small, densely packed regions emerging along the fibres after the additives were introduced.

Because the fibres form in solution and persist into the solid film, manufacturers could adjust conductivity through minor changes to the formulation.

Water and conductivity

When water was introduced, PEDOT:PSS shifted from a firmer film to a soft gel that could stretch without tearing.

As the polymer took up water, its long chains moved further apart, increasing flexibility while the fibre network remained connected.

Lithium salts pulled in even more water, although the plastic still became brittle once it dried.

Conductivity stayed almost constant throughout swelling, a key point for devices that must extend and relax day after day.

Fibers survive the swell

In its wet, stretchable condition, PEDOT:PSS retained the same underlying internal structure that the salts had created earlier.

Water caused the fibres to expand while the smaller packed regions contracted, helping the coating resist cracking during repeated bending.

“Even after introducing water to the material, the fibers remain in the structure,” Gomez said.

With the fibres still linked, engineers can elongate a sensor without the abrupt failures that often occur in brittle films.

Potential medical applications

Pacemaker batteries typically last ten to 15 years, meaning each replacement requires another operation and recovery period.

A stretchable conductor can sit against tissue with less mechanical strain, which could help signals remain steadier during everyday movement.

For skin patches and glucose monitors, a material that preserves conductivity while flexing could improve comfort and maintain better contact.

However, practical devices will still require safe encapsulation and long-term evaluation, since a laboratory film is not exposed to blood and enzymes.

Unknowns that remain

It is still unclear which salts most strongly drive fibre formation and how long the benefit would persist within an operational device.

Because each salt can influence water uptake, charge transport, and structural assembly, choosing additives will involve balancing trade-offs.

“We don’t fully understand how these salts interact with the polymer materials quite yet,” Gomez said.

Further imaging and performance tests should clarify those mechanisms, but safety and longevity will ultimately determine whether implants adopt the approach.

Scaling the discovery

Overall, the study indicates that small chemical additives can reorganise a familiar plastic into conductive fibres without sacrificing its ability to stretch.

The next step is to identify which salt recipes remain stable in warm, wet tissue and which begin to fail after months of use.
